Cannondale Tesoro Neo X 1: At a Glance
Overview
Conquer any terrain with the Cannondale Tesoro Neo X 1, a versatile SUV e-bike designed for urban commutes and rugged off-road adventures. Powered by a 250W Bosch Performance Line CX Smart mid-motor with 85 Nm of torque and a 750Wh battery, this bike offers robust pedal assist and a range of up to 175 km. Its 29-inch wheels (27.5-inch for smaller sizes) and sturdy SmartForm C1 Alloy frame, with a 161 kg load capacity, ensure comfort and durability for carrying gear or navigating trails. Integrated lighting enhances safety, making this e-bike a stylish, reliable choice for all-terrain exploration.
Key Features
- Bosch Drive System: The Bosch Performance Line CX Smart 250W mid-motor delivers 85 Nm of torque, paired with a 750Wh PowerTube battery for a range of up to 175 km, effortlessly tackling inclines and long distances.
- Frame & Fork: The SmartForm C1 Alloy frame features internal cable routing, rack/fender mounts, and a removable battery for convenience. The SR Suntour XCR34 fork with 100mm travel ensures smooth handling on mixed terrains.
- Shifting & Brakes: A Shimano LinkGlide 10-speed derailleur provides smooth, durable shifting, while Riderever Attack-XU 4-piston hydraulic disc brakes (203mm rotors) offer powerful, reliable stopping.
- Wheels & Tires: Schwalbe G-One Allround tires (29×2.25″ or 27.5×2.25″ for small sizes) deliver excellent grip and comfort for city streets and off-road trails.
- Lighting & Safety: Integrated Axa Blueline 30 front and rear lights ensure visibility and safety for evening or low-light rides.
Why Choose the Tesoro Neo X 1?
The Cannondale Tesoro Neo X 1 is a premium SUV e-bike built for cyclists who demand versatility and performance. Ideal for urban commuting, off-road adventures, or carrying heavy loads (up to 161 kg), its powerful Bosch motor, robust construction, and high-quality components deliver a seamless riding experience. Whether cruising through city streets or exploring mountain trails, this all-terrain bike combines style, safety, and functionality for unforgettable rides.
Note: Pedals are not included—be sure to order compatible pedals to complete your setup!
Technical Specifications
| Category | Details |
|---|---|
| Weight | Not specified (assumed ~25 kg for e-bike class) |
| Max Load | 161 kg (including rider and payload) |
| Drive | Chain: Shimano LinkGlide, 10-speed |
| Cassette | Shimano LinkGlide, 11-43, 10-speed |
| Front Derailleur | None (single chainring) |
| Circuit | 10-speed derailleur |
| Rear Derailleur | Shimano LinkGlide, 10-speed |
| Crankset | FSA Bosch E-Bike, 38T |
| Motor | Bosch Performance Line CX Smart, 250W, 85 Nm, 25 km/h max assist |
| Battery | Bosch PowerTube, 750Wh, removable, dual battery compatible |
| Display | Bosch Kiox 300 with LED remote |
| Range | Up to 175 km (109 miles) |
| Brakes | Front Brakes: Riderever Attack-XU, 4-piston hydraulic disc, 203mm rotors Rear Brakes: Magura MT C, 2-piston hydraulic disc, 203mm rotors Brake Lever: Riderever Attack-XU / Magura MT C |
| Frame Set | Fork: SR Suntour XCR34, 100mm travel, coil, boost spacing, 44mm (S) / 51mm (M, L) offset Frame: SmartForm C1 Alloy, removable 750Wh downtube battery, integrated front running light, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection, rack/fender mounts, HDT child seat/cargo mount compatible Frame Shape: Standard (non-step-thru) |
| Components | Handlebar Tape: Cannondale Bar Tape, 3.5mm Handlebar: Cannondale 3, 6061 Alloy, 680mm width Saddle: Fizik Terra Argo X7, 150mm Stem: Cannondale Adjustable, A-headset, 31.8mm Headset: Integrated, 1-1/8″ – 1-1/2″ Seat Post: Parallelogram Suspension Seatpost, 31.6, 25mm setback, 50mm travel, 300mm (SM), 350mm (MD), 400mm (LG) |
| Wheels & Tires | Spokes: Stainless steel, 14g Front Hub: Shimano MT400, 15x110mm thru-axle Front Rim: WTB ST i29 TCS, 32h, tubeless ready Tires (Front): Schwalbe G-One Allround, 29×2.25″ (622x57mm) or 27.5×2.25″ (584x57mm, small size) Rear Hub: Shimano MT400, 12x148mm thru-axle Rear Rim: WTB ST i29 TCS, 32h, tubeless ready Tires (Rear): Schwalbe G-One Allround, 29×2.25″ (622x57mm) or 27.5×2.25″ (584x57mm, small size) |
| Other | Bottom Bracket: Bosch, press-fit Manufacturer: Cycling Sports Group Europe BV, Geeresteinselaan 57, 3931JB, Woudenberg, Netherlands, kontakt@cyclingsportsgroup.com Lighting: Axa Blueline 30 headlight, Blueline taillight, integrated front running light Color: Not specified Suspension: 100mm travel fork, suspension seatpost Corridors: 10 gears Gender: Unisex Brand: Cannondale Wheel Size: 29 inches (27.5 inches for small size) Frame Material: Aluminum Season: 2023 Switching Type: Derailleur Accessories: Cannondale Urban rear rack (25kg, Racktime compatible), Curana Apollo fenders, kickstand, Abus 4650X frame lock (key-matched with battery lock), SP-Connect phone mount adapter |
Perfect For
- Urban Explorers: Cyclists navigating city streets with heavy loads, needing power and practicality.
- Off-Road Enthusiasts: Riders tackling trails and mixed terrains with confidence and comfort.
- Adventure Seekers: Those craving versatile, safe rides for both daily commutes and weekend escapes.
